Alcohol tester POINT RS-1
Alcohol tester POINT RS-1 is a rapid police alcohol content detector that integrates alcohol detection, voice broadcast, baton, strong magnetic suction, strong light flashlight and other functions.
Alcohol tester POINT RS-1 is a rapid police alcohol content detector that integrates
alcohol detection, voice broadcast, baton, strong magnetic suction, strong light
flashlight and other functions. It is a multi-functional rapid screening alcohol
detector developed and produced by Shenzhen Gotai Special Equipment Co., Ltd.
specifically for the police market. It can quickly, conveniently and accurately
measure the alcohol concentration of human breath, and can Realize data
interaction and link it with the Zero Point 1 evidence-based alcohol detector to
send the test data to the centralized drunk driving management platform through
the 4G wireless network.
|
Product model |
POINT RS-1 |
|
Product type |
Alcohol detector （Chinese standard GB/T 21254-2017） |
|
Sensor specification |
11mmFuel cell type amperometric alcohol sensor |
|
Measurement mode |
Continuous monitoring, rapid screening, automatic extraction |
|
Measurement limit |
0～120mg/100ml BAC |
|
Sensitivity to other gases |
Insensitive to exhaled gases such as propanol and carbon monoxide, the effects are negligible |
|
Pumping method |
Continuous pumping air pump, pumping speed is not less than 0.8L/ min |
|
Operating temperature range |
-5℃～45℃ |
|
Storage temperature |
-40℃～+70℃ |
|
measuring time |
2-10 seconds, support their own adjustment on the instrument, the fastest 1 second results |
|
Clearing time |
When the result of the previous test was 0.1mg/L, it was not more than 5 seconds |
|
Environmental pressur |
600～1400hPa |
|
Ambient humidity |
20～85%r.h. |
|
Display screen |
1.5 inch TFT65535 color display |
|
Storage |
5000 measurements can be stored |
|
battery |
3.7V/1350mAh |
|
Continuous measurement time |
More than 8 hours, about 1000 continuous measurements, depending on the surrounding environment |
|
Flashlight |
Strong LED lighting |
|
Baton |
Support fast flashing, slow flashing LED baton |
|
Strong magnet |
Bottom magnetic function |
|
Voice broadcast |
Intelligent voice prompt |
|
keypad |
Three independent keyboard designs, fast and convenient |
|
Handle design |
Ergonomic, comfortable and non-slip handle design |
|
Indicator light indication |
Alcohol concentration above the set value indicates shining tips, red, yellow and green LED tips |
|
Vibrate |
Vibrate when the alcohol level exceeds the set value |
|
Quick linkage |
The non-inductive linkage synchronously connects to the 0.1 alcohol detector, and synchronously uploads the data to the drunk driving management platform |
|
Dui management platform |
Real-time data upload, data analysis, statistical download, special action, department management |
|
Product size |
Length (380) X outer diameter (40) mm |
|
Product weight |
Approx. 297g (including battery) |
Configuration list：
|
NO. |
Product Name |
Specification |
Quantity |
|
01 |
Alcohol detector |
POINT RS-1 |
1 pcs |
|
02 |
Charger |
1pcs |
|
|
03 |
data cable |
1pcs |
|
|
04 |
Special backpack |
1pcs |
|
|
05 |
Operation manual |
1pcs |
Alcohol tester GOTAI POINT RS-1
Q1: I want to buy your alcohol quick release stick. Can you send me a sample to try?
A: Yes.
Q2: How long does it take to give me a quotation?
A: Within 48 hours.
Q3: What type of sensor is it?
A: Imported large-size electrochemical alcohol sensor.
Q4: What are the test reports for your quick alcohol check stick?
A: Obtain the inspection report from the Chinese police department.
Q5: How long does the delivery cycle take?
A: 1 to 2 months.
Q6: Can the color, flash, and usage standards of the alcohol quick release stick be customized?
A: Can be customized in batches.
Q7: How long is the warranty time of your quick-arrangement rod?
A: One year.
Q8: What scenarios can it be applied to?
A: It can be used by police, military, airports, stations, wine lovers, etc.
Q9: How is your warning function implemented?
A: Realized through red and blue batons, LED flashlights, and electronic whistles.
Q10: What is the measurement mode of RS-1?
A: Quick troubleshooting and automatic detection.
Q11: What is the pumping method of RS-1?
A: Automatic pumping and continuous air pumping during operation.
Q12: How much data can be stored?
A: Can store 10,000 pieces of test data.
Q13: What is the battery capacity of RS-1?
A: 3.7V/1350mAh
Q14: What special functions can RS-1 achieve?
A: It can realize intelligent voice broadcast, strong magnetic suction, and tungsten steel window breaking.
Q15: How much does RS-1 weigh?
A: About 297g (including battery)
Q16: What is the difference between RS-1 and GT8?
A: The biggest difference of RS-1 is the alcohol sensor. It adopts a large-sized electrochemical alcohol sensor, which has simpler design functions, more accurate wine detection function and stable performance. It will be better than GT8 in areas with frequent wine tests and low temperatures.
