G10 epoxy fiberglass laminate

G-10 glass epoxy is the non flame retardant version of FR-4, made of a halogen-free epoxy resin binder and woven fiberglass substrate. It has excellent electrical insulation qualities and high mechani

Compare

G10

INSULATION BOARD

≥ 340 MPa

Flexural strength
perpendicular to laminations

≥ 33 KJ/m²

Charpy impact
strength parallel to laminations

≥ 35 Kv

Electric strength perpendicular to
laminations(at 90℃ in 25# transformer oil)

≥ 5*(10²*10²) MΩ

Insulation resistance
after immersion in water

UL94-HB Level

Combustibility

30 mg

Water absorption

120℃

High mechanical strength at room temperature, strong mechanical strength at high temperature of 120℃, good electrical performance in dry and wet state, flame retardant.
